RCS Display
Outdoor LED Display
Our outdoor LED displays deliver perfect for all Indian weather conditions. They are designed for harsh environments with durable, waterproof construction.
With custom size and high brightness, we ensure clear visibility even in direct sunlight and attract attention with its bright and vivid display in busy areas.
P2.5
P3
P3.8
P4
P4.8
P5
P6
P8
P10


Outdoor LED Display
Features and Benefits
Our LED Display create an best experience by displaying high-quality images and videos that attract people’s
attention in busy areas.
Change promotional messages, seasonal offers or brand-specific campaigns in real-time with demographics based on data driven insights.
Enhances brand visibility and recognition in high-traffic areas, contributing to stronger brand identity.
The Indian market for LED technology is expanding, with increasing availability of local suppliers and support services,
making it easier to source and maintain LED video walls.
Built in various weather conditions including rain, heat and dust our LED display are highly durable. Designed to
function effectively in the extreme temperatures characteristic of the Indian climate.
Outdoor LED Display
Application Scenario

BAPS Mehsana
BAPS Temple

LED Display
LED Display

BAPS Ahmedabad
BAPS Temple

Retail & Shopping Malls
Shopping Malls

Outdoor Advertising

Retail & Shopping Mall

Corporate Offices

Government Projects

Universities & Colleges

Real Estate

Hotels & Resorts

Hospitals & Clinics

Mobile Advertising

Billboards & Hoardings

Financial Institutions

Religious & Cultural

Amusement Parks

Tourist Attractions

Automotive Dealerships
Outdoor LED Display
Available in Flexible
For All Pixel Technology


Outdoor LED Display
Product Specification
Parameter Name | 2.5 | 3.8 | 2 | 4 | 4.8 | 3 |
Model Name | RO25 | RB38 | RB2 | RO4 | RB48 | RB3 |
Pixel Pitch(mm) | 2.5 | 3.8 | 2 | 4 | 4.8 | 3 |
LED Type | SMD1515 / SMD2121 | SMD 1921 | SMD1515 | SMD1921 | SMD 2020 | SMD1415 |
Module Size (mm) | 320×160 | 288×288 | 320×160 | 320×160 | 288×288 | 320×160 |
Module Resolution | 128X64 | 75x75 | 160x80 | 80*40 | 60×60 | 104 X 52 |
Module Weight | 0.46±0.02kg | 0.46±0.02kg | 0.45±0.02kg | 0.41Kg | 0.46±0.02kg | 0.43±0.02kg |
Brightness | 4000 ~4500 CD/m2 | 4500cd/m² | 500 CD/m2 | ≥5500cd/㎡ | >1200cd/m² | 5000 CD/m2 |
Viewing Angle | 140 | 140 | 140 | 160 | 140 | 140 |
Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840HZ | 1920Hz | 1920Hz |
Processing Depth | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit |
Contrast Ratio | 5003:01:00 | 5004:01:00 | 5005:01:00 | ≥6000 : 1 | 3001:01:00 | 5000:01:00 |
Input Voltage | AC90~132V | AC90~132V | AC90~132V | 100-240 VAC±15% | AC90~132V | AC90~132V |
Life Span | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours |
Operating Temperature | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
Curvable | YES | YES | YES | YES | YES | YES |
Video Support | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K |
IP RATING | IP65/IP57 | IP65/IP58 | IP65/IP59 | IP65/IP60 | IP65/IP62 | IP65/IP63 |
Parameter Name | 3 | 5 | 6 | 8 | 10 |
Model Name | RB3 | RB5 | RO6 | RO8 | RO10 |
Pixel Pitch(mm) | 3 | 5 | 6 | 8 | 10 |
LED Type | SMD1921/SMD2121 | SMD1921 | SMD2727/3535 | SMD2727 | SMD3535 |
Module Size (mm) | 192×192 | 320×160 | 192× 192 | 320×160 | 320×160 |
Module Resolution | 64X64 | 64X32 | 32*32 | 40X20 | 32X16 |
Module Weight | 0.23±0.02kg | 0.48kg | 0.4Kg | 0.48±0.02kg | 0.48±0.02kg |
Brightness | ≥5000 CD/m2 | ≥4500 CD/m2 | 5500 cd/㎡ | ≥4000 CD/m2 | ≥5500 CD/m2 |
Viewing Angle | 140 | 140 | 140 | 140 | 140 |
Refresh Rate | >1920Hz | 3840Hz | 1920HZ | 1920HZ | 1920HZ |
Processing Depth | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit |
Contrast Ratio | 9000:1 | 3000:01:00 | ≥5000 : 1 | 3000:01:00 | 3000:01:00 |
Input Voltage | AC90~132V | AC90~132V | AC90~132V | AC90~132V | AC90~132V |
Life Span | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours |
Operating Temperature | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
Curvable | YES | YES | NO | NO | NO |
Video Support | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K |
IP RATING | IP65/IP63 | IP65/IP64 | IP65/IP65 | IP65/IP66 | IP65/IP67 |
