RCS Display
Indoor LED Display
Our indoor LED displays offer high-resolution displays and customizable sizes for any indoor space. Our product offers vibrant, eye-catching content with low energy consumption and long life. Quiet operation, modern display solution, wide viewing angles and designed to update your business in real-time.
P1.2
P1.5
P1.8
P2
P2.5
P3
P3.076
P3.8
P4
P4.8
P5


Indoor LED Display
Features and Benefits
Our LED Display create an best experience by displaying high-quality images and videos that attract people’s
attention in busy areas.
Change promotional messages, seasonal offers or brand-specific campaigns in real-time with demographics based on data driven insights.
A well-designed LED video wall can enhance the professional appearance of a business or venue, contributing to a stronger
brand image.
Our team understands the unique challenges of your area, ensuring tailored solutions for your outdoor display needs. We’re here to provide reliable, hands-on assistance every step of the way.
The durability and low maintenance requirements often result in lower total cost of ownership.
Indoor LED Display
Application Scenario

Retail Stores

Shopping Malls

Corporate Offices

Conference Centers

Jeweller Sector

Hotels & Resorts

Hospitals & Clinics

Universities & Colleges

Restaurants & Cafes

Media & News Sector

Museums & Art Galleries

Fashion Shows & Exhibitions

Event Venues

Government Buildings

BAPS Mehsana
BAPS Temple

LED Display
LED Display

BAPS Ahmedabad
BAPS Temple

Retail & Shopping Malls
Shopping Malls
Indoor LED Display
Available in Flexible
For All Pixel Technology


Indoor LED Display
Product Specification
Parameter Name | 1.25 | 1.53 | 1.83 | 2.5 | 3.8 | 2 |
Model Name | RI12 | RI15 | RI18 | RI25 | RB38 | RB2 |
Pixel Pitch(mm) | 1.25 | 1.53 | 1.83 | 2.5 | 3.8 | 2 |
LED Type | SMD2020/SMD1010 | SMD1212 | SMD1515 | SMD2020 | SMD 1921 | SMD1515 |
Module Size (mm) | 320×160 | 320×160 | 320×160 | 320×160 | 288×288 | 320×160 |
Module Resolution | 256*128 | 208*104 | 174×87 | 128X64 | 75x75 | 160x80 |
Module Weight | 0.48±0.02kg | 0.49±0.02kg | 0.46±0.02kg | 0.25 | 0.46±0.02kg | 0.45±0.02kg |
Brightness | 500 CD/m2 | 501 CD/m2 | 500 CD/m2 | 1200 cd/㎡ | 4500cd/m² | 500 CD/m2 |
Viewing Angle | 140 | 140 | 140 | 140 | 140 | 140 |
Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
Processing Depth | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit |
Contrast Ratio | 5000:01:00 | 5001:01:00 | 5002:01:00 | 5003:01:00 | 5004:01:00 | 5005:01:00 |
Input Voltage | AC90~132V | AC90~132V | AC90~132V | AC90~132V | AC90~132V | AC90~132V |
Life Span | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours |
Operating Temperature | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
Curvable | YES | YES | YES | YES | YES | YES |
Video Support | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K |
IP RATING | IP65/IP54 | IP65/IP55 | IP65/IP56 | IP45 | IP65/IP58 | IP65/IP59 |
Parameter Name | 4 | 4.8 | 3 | 3 | 5 |
Model Name | RI4 | RB48 | RB3 | RB3 | RB5 |
Pixel Pitch(mm) | 4 | 4.8 | 3 | 3 | 5 |
LED Type | SMD2121 | SMD 2020 | SMD1415 | SMD1921/SMD2121 | SMD1921 |
Module Size (mm) | 320×160 | 288×288 | 320×160 | 192×192 | 320×160 |
Module Resolution | 80×40 | 60×60 | 104 X 52 | 64X64 | 64X32 |
Module Weight | 0.46±0.02kg | 0.46±0.02kg | 0.43±0.02kg | 0.23±0.02kg | 0.48kg |
Brightness | ≥500 CD/m2 | >1200cd/m² | 5000 CD/m2 | ≥5000 CD/m2 | ≥4500 CD/m2 |
Viewing Angle | 140 | 140 | 140 | 140 | 140 |
Refresh Rate | 3840Hz | 1920Hz | 1920Hz | >1920Hz | 3840Hz |
Processing Depth | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit | 12~14 Bit |
Contrast Ratio | 3000:01:00 | 3001:01:00 | 5000:01:00 | 9000:1 | 3000:01:00 |
Input Voltage | AC90~132V | AC90~132V | AC90~132V | AC90~132V | AC90~132V |
Life Span | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours | >1,00,000 Hours |
Operating Temperature | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
Curvable | YES | YES | YESS | YES | YES |
Video Support | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K | HD,SD,FHD, UHD,2K,4K |
IP RATING | IP65/IP61 | IP65/IP62 | IP65/IP63 | IP65/IP63 | IP65/IP64 |
